EBW® SERIES
SPILL CONTAINERS
EBW® Series spill containers provide an economical solution
for the collection of spilled product during normal tank filling
of underground storage tanks. They are available in both
grade level and below grade level models to meet the needs
of your application and preference. The complete lineup of
EBW® Series spill containers provides a basic, easy-to-install,
and simple-to-maintain spill containment solution.
HIGHLIGHTS
SPECIFICATIONS
• Available in both grade level and below grade level models
Components
to meet the needs of your application and preference.
• Single wall containment protection.
• The flexible polyethylene container is designed to move
with natural ground movements.
• Drain and pump options facilitate easy return of spilled fuel
back into the tank.
Cover
6
Gravel guard
2
Cast iron deflector ring
7
Concrete anchors
3
Flexible polyethylene shell
8
Locking cover
4
Cast iron threaded base
9
18" Cast iron manway
5
Cast iron slip-on base
SERVICE STATION
HARDWARE
• A cast iron base provides stability (NPT or BSPT).
• Threaded base for new installations.
• Slip-on grade level models for retrofit applications use a
1
Grade Level
1
2
gasket flanged bolt system to secure the spill container to
the riser pipe and are designed to eliminate the need to
remove the riser pipe from the tank when installing.
3
7
• Covers available in a variety of colours to clearly identify
product contained in the tank and prevent cross drops.
6
Grade Level Spill Containers
• 5 gallon capacity.
• Grade level spill containers feature a durable cast iron
deflector ring which provides protection from heavy traffic
and truck plows while diverting water away from the spill
container top.
4
Grade Level Retrofit
Below Grade
1
2
9
• The container is equipped with a gravel guard to prevent
3
backfill material from filling in around the movable shell,
mitigating issues with ground movement.
8
• Composite, cast iron, or aluminum cover options.
3
Below Grade Level Spill Containers
• 5 gallon and 15 gallon capacity options.
• Below grade level spill containers feature a hinged,
locking, watertight cover that prevents water from entering
the containment.
5
4
• They include an 18" wide, 8" deep cast iron manway with
either a composite or steel lid that allows forecourt traffic to
pass cleanly over its top.
145
